JSZVR2-12C
VOLTAGE TRANSFORMER
□ 12kV Indoor Single-Phase Epoxy Resin Type
Epoxy resin casting and full enclosed construction, is used indoor
for measuring , electric energy and protective relaying in
single-phase or three-phase AC circuit with the frequency 50Hz
or 60Hz and highest voltage for equipment 12kV.
The product has the feature of high reliability, low magnetism of
core, large creepage distance of external insulation and
maintenance free etc.
Technical Data
1、Installation site indoor
2、Rated frequency 50/60Hz
3、Load power factor: cosΦ=0.8 （lagging）
4、Technical standard accords with IEC 60044-2
(IEC 61869-1&3)
Specification
|
Type |
Rated primary Voltage （kV） |
Rated secondary Voltage （kV） |
Accuracy classes combination |
Rated output (VA) |
Thermal limiting Output (VA) |
Rated Insulation level (kV) |
|
JSZVR2-12C |
11 |
0.11 |
0.2 |
25 |
500 |
12/28/75 |
|
0.5 |
50 |
|||||
|
1 |
80 |
|||||
|
0.11/0.11 |
0.2/0.2 |
10/10 |
250/250 |
|||
|
0.2/0.5 |
15/30 |
|||||
|
0.11/0.22 |
0.2/6P |
15/500 |
500 |
|||
|
0.5/6P |
30/500 |
